THE W5 - CAR SEAT
The W5 is a semi reclined version of the W1i shape. This is suited for low sports prototype race vehicles and race simulators.
The seat is available either with a carbon, or a black GRP front finish and both models have a smooth black rear surface. Moulded low profile seat belt harness holes are included. The W5 seat is a single composite skin and will need brackets made to fit to the various vehicles. No backframe option exists for this shape. Single skin only.
Low back W models are most suitable when a headrest is not practical, maybe for an application where there is already a headrest support in existence.
KEY FEATURES
- The W5 has a semi reclined driving position between the W1i and ultra-laid back W3 Tillett car seats.
- Most suited to low sports prototype race cars or racing simulators.
- The seat can accommodate a driver up to approximately 100kg with a 36-inch jeans waist size. W6 the XL version is also available.
- No backframe options are available with the W5 car seat. Single skin shell only.
- Low profile moulded seat belt harness holes included, enabling a five or six point race harness, which is strongly advised with a reclined seat.
- The W5 weight is approximately 2kg (Weight of seats can vary by 10%)
- Body mirroring shape gives the driver full support, unhindered steering control and maintains ultimate comfort over long periods of time.
- Custom brackets will need to be made by the customer to fit the W5, as this seat is a single skin composite shell without integrated fittings.
- Two finishes available, gloss CARBON/GRP & black GRP.
- Manufactured at the Tillett factory using their specialist manufacturing system, which creates mouldings of quality, strength and accuracy.
- Does not require padding, allowing ultimate feedback from the car, essential for a competition seat. Additionally, there is zero water absorption due to the seat not requiring any foam covering, making the seat extremely practical for an open top race car.
- Additional covered panel options available if required. A panel set will add approximately 1kg.
- All seat panels are customisable, contact the office directly for further information and prices
- All Tillett car seats are premium quality products designed and manufactured in the United Kingdom.
COMPATIBLE SEAT PANELS
- See Photo gallery for seat dimensions
- If item shows as "Special Order" that means we currently have no stock. Placing an order will reserve the next available unit/s for you.
- Lead times can vary, please email us if you need an estimated arrival time if item shows as Special Order
