Sim Lab P1-X Sim Racing Cockpit
- Worldwide Shipping
- 2 Year Manufacturers Warranty
- Authorised Sim Lab Reseller
The SimLab P1X is our best selling pro-level racing simulator cockpit. We have supplied P1 X sim racing cockpits to pro drifters James Deane & Conor Shanahan, factory Aston Martin GT3 driver Charlie Eastwood and WRC rally driver Craig Breen to name drop but a few! it is the sim chassis of choice for dozens of our LMP, F3, GT3 and club racing customers worldwide.
Why is The P1X The Best Sim Racing Chassis?
it's just a really good product - plain and simple! Richard and the guys at SimLab have spent a long time developing the P1-X into its current form. This is not simply an 8020 profile rig bolted together with off-the-shelf parts, it has been developed over time by a team who understand and are passionate about sim racing and understand what pro and amateur race drivers want in a professional racing simulator. The P1X uses bespoke, laser cut components and anodised aluminium bracketry to make the rig ultra rigid, adjustable and also look great!
The Sim Lab P1 X is designed to work flawlessly with all kinds of accessories such as the integrated monitor mount system which is available for single or triple screens. A matching, free standing triple monitor stand is also available in standard or HEAVY DUTY variant for screens over 32"
Pedal Tray
The newly designed pedal tray gives the extra flexibility needed to handle a wide variety of seating positions. It covers movement in all directions including completely flipped around to have the pedals sit on the deck. Also, its configured in such a way that it will accommodate different pedals sets, and the possibility to add an adjustable heel plate or pedal sliders. By lowering the seat (and using the Sim Lab SF-1 Seat) and raising the pedal tray, a formula/LMP seating position is easy to achieve.
Connector Plates
The uprights are the main focal point when creating a rigid frame. Steering forces are creating a moment (torque force) at the base of the uprights, even more so with the high forces Direct Drive wheels are operating. To counter these effects, a play-free connection of the upright is essential. These sandwich plates lock the uprights firmly into place. Because they are easy to install, success is guaranteed.
Side mount
The P1-X is fitted with a shifter/accessories mount, running from the uprights to the back of the rig. Can be mounted both left and right. In addition, extra 2 profiles are provided to add the possibility of multiple configurations.
Wheel Deck Version:
- Fanatec Club Sport Wheels
- Fanatec Elite wheel series
- Fanatec Podium DD wheels DD1, DD2
- Thrustmaster wheels (T500RS, TC-PS, TS-XW, T300RS, T-GT)
- Logitech G25, G27, G29
- AccuForce V1/V2
Front Mounting Version:
- Fanatec Club Sport Wheels
- MiGe 130ST (small, big)
- Bodnar 50 series
- Lenze MCS12 series
- SimuCube 2 Sport, Pro, Ultimate
Podium DD wheel Version:
- Fanatec Podium DD1 & DD2 wheel
Key Features:
- Base structure featuring 160 x 40 mm aluminium profiles. Special sandwich plates lock the uprights from any movement.
- Dashboard bracket securely fixates you Servo Drive wheel (Mige, SimuCube)
- Movable seat position (can be positioned inclined)
- Steering wheel position fully adjustable
- Pedal position fully adjustable
- Side mounting point included that can be configured in different ways
- Fanatec pedals can be mounted without additional hardware. Heusinkveld pedals can be mounted without extra materials, all bolts/nuts included. Heel plate can be purchased separately.
- Different sizes of spare bolts to mount seat brackets, shifters, and pedals
Specification:
- Aluminium profiles and mounting materials
- Base frame consists of 40 x 160 mm profiles
- Steering wheel uprights 40 x 120 mm profiles, length 780 mm
- Aluminium profile type: Item 40 mm slot 8
- P1 chassis dimensions: 1400 mm x 580 mm (length x width outer dimensions)
- Steering wheel height adjustability: 0 700 mm
- Suitable for 200 cm body length
- Total weight 55 kg.
Included in the package:
- Aluminium profiles and mounting materials
- Bolts for mounting seats and peripherals
- Schematic instructions available for download
- Rubber feet
Not Included in the package:
- Adjustable feet separately
- Seat
- Seat bracket
- Mounting plates for a shifter
- Heel plate
