The integrated RTK module provides various industries, such as agriculture and construction, with centimeter-level positioning and mapping of large areas from the air. The module is capable of horizontal accuracy of 1 cm 1 ppm and vertical accuracy of 1.5 cm 1 ppm. Obtaining this data takes only (approximately) 3 minutes, but for complex and interference-prone areas, you can use the EVO II Pro with optional NTRIP RTK base stations and network to improve mapping accuracy and stability in data acquisition.



When using an NTRIP network, no GCP is needed, as the drone connects directly to the network. The drone records the original satellite observational data, camera exposure, and more, and it supports PPK post-processing to adjust the accuracy of your collected data.

With Autel Explorer, you can use the EVO II Pro V3 drone to complete mapping missions using a variety of features and functions.

• Multi-NTRIP profile saving: This allows the drone to restart a mission after a battery change from where it left off.
• Photo replication: You can save all of the gimbal, camera, and drone movements, producing a full record of a mission that can then be repeated.
• Multi-battery missions: Create and save multiple NTRIP profiles for different locations without having to manually input account info for each flight.
• Create rectangular or polygon mapping missions
• Supports double grid mapping for additional angles
• Gain complete manual control over camera settings
• Nonstop turning on corners saves time and battery life
• Customizable course headings to meet orientation requirements
